| MAN L23/30H series Marine Generator |
| 844KW MAN 6L23/30H Marine Generator |
|
|
| Product Name |
844KW MAN 6L23/30H Marine Genset |
| Product No. |
JVMGS03-002 |
| Genset Data |
|
| Power |
844KW |
| Speed |
750RPM |
| Frequency |
50HZ |
| Voltage, Phase and Wire |
400V,3Ph, 4 |
| Dimensions(L*W*H) |
6004mm*2250mm*2382mm |
| Weight |
18.5T |
| Engine Data |
|
| Brand |
MAN B&W |
| Model |
CCFJJV-844 |
| Engine Model |
MAN 6L23/30H |
| Type |
in-line,4 stroke,turbocharged |
| Bore * Stroke |
225mm*300mm |
| Rated Power |
888KW |
| Rated Speed |
750RPM |
| Alternator Data |
|
| Brand |
Siemens, Hyundai |
| Exciter Type |
Brushless, self-excite |
| Power Factor(CosΦ) |
0.8 lagging |
| Regulator Approach |
AVR |
| Cetification |
ISO9001: 2000 |
| Insulation Grade |
H/F |
| Class Certificate |
CCS, BV, ABS, LR, GL, NK, KR, RINA, DNV |
|
|
|
|
