1.Eye-plug type lashing rod(LR-1)
2.Eye-eye type lashing rod (LR-2)
3.Triangle hook-swivel head type lashing rod(LR-3)
4.Eye-swivel head type lashing rod (LR-4)
5.knob-swlvel head lashing rod (LR-5)
6.Vertical, knob-swivel head type lashing rod (LR-6)
|
MODEL NO. |
L(mm) |
B.L. |
WEIGHT |
|
LR-1 |
2400/4570 |
420KN |
11/20kg |
|
LR-2 |
2400/4570 |
500KN |
10/19kg |
|
LR-3 |
2200/4600 |
11/20kg |
|
LR-4 |
2400/4700 |
11/20kg |
|
LR-5 |
2450/4700 |
12/21kg |
|
LR-6 |
1800/4300 |
12/21kg |
Matrial: Forged steel& high tensile steel
Finish: Hot dipped galvanized
Remarks: other lengths, materials and finish upon request |
